Feature:
ALS, IR LED and Proximity Detector in an Optical Module
Ambient Light Sensing (ALS)
Approximates Human Eye Response
Programmable Interrupt Function with Upper and Lower Threshold
Up to 16-Bit Resolution
High Sensitivity Operates Behind Darkened Glass
Low Lux Performance at 0.01 lux
Proximity Detection
Fully Calibrated to 100 mm Detection
Integrated IR LED and Synchronous LED Driver
Eliminates Factory Calibration of Prox
Programmable Wait Timer
Wait State Power 90 A Typical
Programmable from 2.7 ms to > 8 sec
I2C Interface Compatible
Up to 400 kHz (I2C Fast-Mode)
Dedicated Interrupt Pin
Sleep Mode Power - 2.2 A Typical

Applications:
Cell Phone Backlight Dimming
Cell Phone Touch-screen Disable
Notebook/Monitor Security
Automatic Speakerphone Enable
Automatic Menu Pop-up
Digital Camera Eye Sensor

Package Included:
1 x APDS-9930 RGB Gesture Sensor Modul
