Mechanical Properties
Operating force: one-touch switch =8N
Mechanical life: =2000 Operations
Dial stroke: 1mm
Vibration: Per GJB360A-96
Working temperature: -25 ? ~ + 70 ?
Storage temperature: -40 ? ~ + 85 ?
Solderability: After flux 230 ± 5 ? for 5 ± 0.5seconds, 95% coverage
Resistance to soldering heat: 260 ± 5 ? for 5 ± 1 seconds

Electrical Characteristics
Switching capacity (frequently switched): 25 mA 24VDC
Switching capacity (infrequently switched): 100mA 50VDC
Contact resistance (initial value): =50mO
Contact resistance (after the test): =100mO
Insulation resistance: =1000MO at 500VDC
Compressive strength: 500VDC for 60 seconds.1mA
Pole occasion capacitance: =5pF

Dimensions
