Suction cup design: Using the vacuum cup, the robot arm can be stably fixed on the table to prevent the robot arm from slipping due to movement.
Item |
Specification |
Size |
154*140*246mm |
Body weight |
about 0.9kg |
Material |
aluminum alloy and surface sandblasting and oxidation |
DOF |
5 DOF+gripper |
Power supply |
7.5V 6A DC power adapter |
Controller system |
xArm 1S bus servo controller |
Software |
PC software and mobile APP |
Servo |
single shaft/LX-15D/LX-225 intelligent bus servo |
Control method |
iOS/Android mobile APP/PS2/mouse/PC software |
Package size |
360*320*120mm (unassembled) |
Package weight |
about 2.2kg |
Packing List (Unassembled) |
1* Robotic arm brackets (with servo horns) |
Packing List (Assembled) |
1* xArm 1S robotic arm(ready-to-use) |
